C3X Lumis
ELECTRONICS
Input signals:
gilded RCA type connectors
1.0 V
pp
/ 75 Ω, negative synchronisation
4 pin mini-DIN connectors
Y: 1.0 V
pp
/ 75 Ω, negative synchronisation
C: 0.286 V
pp
/ 75 Ω, [NTSC burst rated level]
0.3 V
pp
/ 75 Ω [PAL, SECAM burst rated level]
rPb/RGB H/V)
- Component signal
Y: 1.0 V
pp
/ 75 Ω,
negative or 3 level synchronisation
[HDTV]
PrPb:0.7 V
pp
/ 75 Ω
- RGB Signal
R,B: 0.7 V
pp
/ 75 Ω
G: 0.7 V
pp
/ 75 Ω, HV synchronisation
1.0 V
pp
/ 75 Ω,
negative or 3 level synchronisation
[HDTV]
Positive or negative TTL, 5 V
pp
/ 1 kΩ
female DB15HD-type connectors
R,B:0.7 V
pp
/ 75 Ω
G:0.7 V
pp
/ 75 Ω, separate H, V or HV synchronisation
1.0 V
pp
/ 75 Ω,
negative or 3 level synchronisation
[HDTV]
Positive or negative TTL, 5 V
pp
/ 1 kΩ
Control: Keypad on back panel, remote control,
via RS232 and USB from PC or domestic
automation devices
Horizontal frequency: from 15 to 80 kHz (up to UXGA format,
65 Hz)
Vertical frequency: 24Hz - 30Hz - 48Hz~100Hz
Video standard: automatic selection (PAL
B,G,H,I,M,N,60, SECAM, NTSC 3.58
and 4.43)
High definition standard: ATSC HDTV (480p, 720p, 1080i, 1080p)
Graphic standards: VGA, SVGA, XGA, SXGA, UXGA
Colour temperature: from 5500K to 9000K
Outputs: 3 outputs (+12 V 100mA) jack (TRIG1 ac-
tive with system switched on, TRIG2 active
with16:9 format ratio selected, TRIG3 for
activating the anamorphic lens)
Image vertical shift range: +50% image
13 TECHNICAL SPECIFICATIONS
GENERAL INFORMATION: PROJECTOR
Power cable: (EU, UK and US); 2m long
Power supply: from 100 to 240 V AC, tolerance +/- 10%
frequency from 48 to 62 Hz
Absorption from mains: 420 W max
Fuse: FUSE T 10 A L H 250V
Dimensions: 458 x 210 x 455 mm (WxHxD)
18,03 x 8,26 x 17,91 inches (WxHxD)
Weight (approx.): 11 kg
Operating temperature: 10 to 35°C
Shipping temperature: -15 to 55°C
Storage temperature: -15 to 55°C
Humidity: 20% to 95% without condensation
Safety: EN 60950
Portability: considered “desktop equipment”
Electromagnetic
compatibility: EN 55022 Class B
EN 55024
EN 61000-3-2
EN 61000-3-3
UL in approval
Transport: IEC 68-2-31, IEC 68-2-32
