CRYSTAL4-SH
User Guide
56
Set the Electronic Perfect Fit via Serial interface
Send one of the above commands via the RS2332 serial interface, choosing which one
corresponds to the value number that better fits your requirements to match the 16:9
image aspect.
Digital Zoom
value
Aspect RS232 command (Hex format)
0 Anamorphic
2,35:1
BE EF 1A 0C 00 A8 3E 11 00 00 00 00 00 00 00 00 00 00 00
-25 16:9 BE EF 1A 0C 00 09 7E 11 00 00 00 E7 FF 00 00 00 00 00 00
-26 16:9 BE EF 1A 0C 00 C5 BF 11 00 00 00 E6 FF 00 00 00 00 00 00
-27 16:9 BE EF 1A 0C 00 D0 FF 11 00 00 00 E5 FF 00 00 00 00 00 00
