STEPS TO FOLLOW TO REALISE A CUTTING
1 Lift slightly the blades safeguard to save height of the flange and then drag it completely leftwards Fig.6
before you can lift it totally.
2 Resting the bars upon the roller so that you can e asily move t he bar forward as per the pr edetermined
measurement. Place the bar in the thro at between th e tw o blad es. Lo wer back the blades saf eguard and pu s h it
rightward to free the pedal (the mechanism that operates the cutting).
Note: CEL models are equipped with a safety system that when the blades safeguard is lifted, the blades would not
be able to cut the material.
3 Once the safeguard has be en released, we can effe ctuate a cutting, either by pres sing the peda l or pullin g
the grip.
Never try to make a cut while the safeguard is lifted as the material to cut can leave the cutting throat and
cause damage.
5. SOLUTIONS TO MOST FREQUENT ANOMALIES
ANOMALY POSSIBLE CAUSE SOLUTION
Fault of the electrical power supply
Check the power supply in th e switch
board. Check the position of t he circuit
breaker and the residual cur rent device
in the switch board.
Make sure the extension cable is in good
state and its fitti ng in the two extremes is
correct.
activation of th e thermal protection of
the single-phase switch
Wait until the motor has co oled down
and re-activate the thermal protection
Motor does not start
Switch damaged Replace it
Motor starts very slowly and takes too
long to reach its revolutions
Condenser damaged.
(Single-phase motors)
Replace it
Belt loose or blunt Tighten the belt or replace it
Blades blunt
Change the cu tting face of the blad e
or replace it
Cutting power is too low
Power drop down of the motor
Let th e technical service ch eck th e
motor.
Premature wearing of the belts The belts slide over the pulleys Tighten the belts
6. TECHNICAL CHARACTERISTICS
DETAILS CEL-30 TRIF. CEL-30 MONF. CEL-35 TRIF. CEL-45 TRIF.
MOTOR POWER Kw.
1,5 1,5 2,2 3
MOTOR TENSSION
230/400V~
50-60Hz
230V~
50-60Hz
230/400V~
50-60Hz
230/400V~
50-60Hz
MOTOR R.P.M.
3000 3000 3000 3000
NET WEIGHT Kg. 247 247 391,6 666
DIMENSIONS L x A x H mm. 831x544x728 831x544x728 933x631x689 1147x640x915
CUT PER MINUTE 105 105 100 60
OIL CAPACITY L 1 1 1.3 9
