TECHNICAL SPECIFICATIONS - TECHNISCHE ANGABEN
OPERATING PRESSURES - BETRIEBSDRÜCKE
Discharge pressure - Hochdruckbereich
SD 22 SD 23 SD 30 SD 40 SD 60 SD 80 SD 125 SD 210
Air cooled (21°C)
Luftgekühlt (21°C) 8÷9 bar 8÷9 bar 8÷9,5 bar 8,5÷10 bar 8,5÷10 bar 8,5÷9,5 bar 15÷19,5 bar 16÷20 bar
Water cooled
Wassergekühlt 8,5÷10 bar 8,5÷10 bar 8,5÷10 bar 8,5÷10 bar 8,5÷10 bar 9,5 bar 17 bar 17 bar
Suction pressure - Niederdrück
Start / End of freezing cycle - Beginn / Ende der Gefrierfase
SD 22 SD 23 SD 30 SD 40 SD 60 SD 80 SD 125 SD 210
0,8÷0,1 bar 0,8÷0,1 bar 0,8÷0,1 bar 0,8÷0,1 bar 0,8÷0,1 bar 0,8÷0,1 bar 3,6÷1,5 bar 2,4÷1,3 bar
SD22 SD22W SD23 SD23W SD30 SD30W SD40 SD40W SD60 SD60W SD80 SD80W SD125 SD125W SD210 SD 210 W
Electric voltage 230/50/1 230/50/1 230/50/1 230/50/1 230/50/1 230/50/1 230/50/1 230/50/1
Normale Netzspannung -10 ÷ +10% -10 ÷ +10% -10 ÷ +10% -10 ÷ +10% -10 ÷ +10% -10 ÷ +10% -10 ÷ +10% -10 ÷ +10%
Condensation Air Water Air Water Air Water Air Water Air Water Air Water Air Water Air Water
Kühlung Luft Wasser Luft Wasser Luft Wasser Luft Wasser Luft Wasser Luft Wasser Luft Wasser Luft Wasser
Bin Capacity (kg)
Speiker Kapazität (kg) 6,5 12 12 17 20 30 50 80
Net weight (kg)
Netto Gewicht (kg) 28 33 40 45 48 61 94 131
Compressor power HP
Kompressorleistung PS 1/5 1/5 1/5 1/4 3/8 1/2 1 1.5
Running amps
Ampere 2.2 2.2 2.2 2.2 3.2 3.8 5.3 5.5
Start amps
Start Ampere 9 9 9 11 17 20 29 32
Power (Watts)
Leistung (Watt) 340 340 350 380 530 650 1200 2000
Power cons. in 24 hrs (Kwh)
Stromverbrauch in 24 std (Kwh) 7 7 7 7.5 10.5 13 24 35
Wire size (mm
2
)
Kabelanzahl (mm
2
) 3 x 1 3 x 1 3 x 1 3 x 1 3 x 1 3 x 1 3 x 1,5 3 x 1,5
Refrig. charge R 134a (gr)
Kühlmittel Füll. R 134a (gr) 210 190 190 190 260 240 280 240 300 270 450 300 – – – –
Refrig. charge R 404a (gr)
Kühlmittel Füll. R 404a (gr) – – – – – – – – – – – – 630 500 660 500
R efrigerant metering device Capillary tube Capillary tube Capillary tube Capillary tube Capillary tube Capillary tube Capillary tube Capillary tube
Kältemittel-Expansionssystem Kapillarrohr Kapillarrohr Kapillarrohr Kapillarrohr Kapillarrohr Kapillarrohr Kapillarrohr Kapillarrohr
