Simagic GT1 HUB User Manual
HUB Function
the C toggle switch is a three position lock switch, from top to bottom,
green, red and blue;
Represent different working modes of hub.
1 Toggle switch at C green (top): parameter setting calibration working mode.
② Toggle switch to C Red (middle): double clutch mode (only for Four paddle version, ABCD)
The clutch paddle is in working and semi clutch mode, and the linear clutch paddle on either
side is in semi clutch state,Pull the linear clutch paddle on the other side to the full clutch state.
Other cases and knobs can be reflected into the game.
3
Toggle switch to C blue (bottom): dual axis mode (only for Four paddle version, ABCD)
The linear clutch paddles on both sides can work independently。 Two linear clutch paddles
can be mapped into two input axis for separate use, and other buttons and knobs can be
mapped into the game.
*Double paddle AB models do not have clutch mode. Only gear shift.
N: Set the steering wheel rotation angle to 360°
P: Set the steering wheel rotation angle to 900°
E: Set the steering wheel rotation angle to 540°
R: Set the steering wheel rotation angle to 1080°
Button for wheel rotation quick settings
