１１
Screw bag
Square nut
Interlock with M6 × 16mm flat head
screws
M6 × 16mm flat head screws
To be used with bracket stand
bottom hole connection. 16mm Allen
wrench.
Custom slider nut:
To be used in slots on the side of the
base along with supplied bracket.
The unique design of this allows easy
adjustment of the whee base to be
closer or farther away from driver.
M6
×
16mm flat head screws
To be used for securing wheelbase
bottom directly to fixed support.
Allen wrench
M6 × 10mm flat head screws
To be used with bracket stand
side hole connection4mm Allen
wrench. 4 mm screw.
