M10 base is made of integrated design, and the body is clean and less port.
Base introduction
Host vent:
Used for heat dissipation
during base operation,
Do not block.
USB Can Bus port.Can
be used to connect
Simagic peripheral
converter box or future
Simagic accesories
Reset hole：
The M10 has a memory protection function. If
the user encounters problems with the
simulator system such as failure and no angle
limit state in use, he can use a pin or similar
object to reset the wheelbase.
USB-B port：
Use the factory
equipped USB-B
data cable to
connect to the PC.
USB port:
Spare interface, SIMAGIC test interface
Used for product inspection, after-sales
inspection, etc.
