scorpION3 5200969 Rev 4 20
Hot Key Tip: Pressing the down arrow and right arrow at the
same time will jump the MMI menu to the Fault Code Status
Screen.
Bar Info Screen shows the bar Software Version number, bar
serial number, the Up Hours (total run time for the bar and Time
(a reset able timer for maintenance).
Bar Reset Screen shows the bar address and first four / last
four digits of the bar serial number (to confirm bar) and allows
resetting (rebooting) of the bar software. Settings not “saved
local to bar” will be lost. Settings “saved local to bar” will
remain. Bar Reset will reset the Time (the reset able timer) to
zero.
From Select Bar, Preset or System Monitor review and
adjustment of any of the 14 (P1 through P14) preset operating
parameters may be selected. The menus under the Preset
selection are the same as under the bar set-up selection but may be
saved as a one of fourteen convenient preset set-up for
downloading into scorpION3 bars. At the end of setting the preset
the preset number (P1 through P14) may be assigned and the
preset saved.
From Select Bar, Preset or System Monitor the system may be
monitored by selecting SYS. This will activate a screen that shows
the number of bars in the system. This screen automatically scrolls
through all bars in the system at a rate of approximately one per
second. The system address of a bar will appear along with its
operating status and fault code if present.
