8
Model
ECOMAXI VB 80 1181 575
ECOMAXI VB 120 1501 935
Note: All the pictures in this manual are for explanation purpose only. They may be slightly different
from the appliance you purchased. Please subject to the actual appearance.
■ Installation Instructions
1. Appliance Moving
● This appliance is quite heavy so that it requires two or more people to move and install, or it may
cause in personal injury or other accidents.
● Please transfer the appliance as its delivery status, do not disassemble it by yourself.
● In order to avoid scratches and deformation on the surface, please add protection board over the
surface of the appliance where may contact hard objects directly.
● Be careful not to touch the fan with your hand or other objects.
●Do not transfer the appliance with inclination over 45°. Do not lay the appliance flat on the floor.
2. Selection and fixation of Installation position
Fig.4 Recommended installation and maintenance space
