Part 3: Installation
■ Basic Installation Tools and Materials Needed
Name
QTY
Usage
Pipe wrench
2 pcs
To connect the water pipes.
Straight screwdriver,
Phillips screwdriver
1 pc per each
To disassemble the housing
cover and connect wires.
Wire scissor or stripper
1 pc
To trim thread and strip wire.
Ball valve
1 pc
To connect the tank inlet water pipes.
Water pipe, Flexible joint
Depend on the actual need
Choose PPR pipes or PAP pipes.
Hot water pipe,
Insulation material
Depend on the length of
the hot water pipe
To insulate.
■ Dimensions
Fig.3 Appliance dimensions
