2
RANGE RATED CERTIFICATION
The maximum power, in heating mode, of Edea boilers can
be adapted, during the installation, to the thermal needs of
the system by modifying the setting of PAR 15 in the
0 .. 100
range.
The setting of PAR 15 = 100 is the factory setting that allows
the boiler to deliver its maximum power in heating mode. It
can be reduced by modifying the setting of PAR 15 as shown
in the table appearing below.
Once the new setting of PAR 15 has been made, the reduced
maximum power value (kW)
for models with power above 35
kW
MUST MANDATORILY be applied beside the boiler’s data
plate. For checks and adjustments after the modification,
refer to the new value for the maximum power.
The useful nominal power levels used are those relative to the
operating conditions (80-60°C) (Pn min - Pn max).
Example for Edea 30 :
– default heating power range: 2,8 - 24,5 setting of PAR 15 = 100
– “reduced” heating power range: 2,8 - 18,9 setting PAR 15 = 80
DESCRIPTION
Edea
30 40
Setting of PAR 15
Min Max Min Max
A - Factory power range (heating) kW 2,8 24,5 4,2 34,1
100
B - Reduced power ranges for
maximum power reduction
(heating)
kW 2,8 21,2 4,2 30,7
90
kW 2,8 18,9 4,2 27,3 80
kW 2,8 16,5 4,2 23,9 70
kW 2,8 14,2 4,2 20,5 60
kW 2,8 11,8 4,2 17,0 50
kW 2,8 9,4 4,2 13,6 40
Boiler technical data plate
