Sime MACK 7 - Technical Data; Overall Dimensions; Working Field; Flexible Oil Pipes with Nipples

2685
2
GB
2. TECHNICAL DATA
2.1 TECHNICAL DATA
2.2 OVERALL DIMENSIONS
2.3 WORKING FIELD
(as EN 267)
Model MACK 7
Output - Thermal power 8
–
18 kg/h - 95
–
213.5 kW
Fuel Light oil, max. viscosity at 20°C: 6 mm
2
/s
Electrical supply Single phase, ~
50Hz 230 V
±
10%
Motor Run current 1.4 A – 2750 rpm – 288 rad/s
Capacitor 6.3
µF
Ignition transformer Secondary 8 kV – 16 mA
Pump Pressure: 7
–
15 bar
Absorbed electrical power 0.30 kW
Flange Burner
370 118 304
160
=
40
45
°
ø 125
317
11
237
D5964
=
127
99 99
190
45
°
213
D6054
0
0.4
Pressure in combustion
chamber – mbar
Light oil output – kg/h
Thermal power – kW
D6176
7 8 9 10 11 12 18
90 110 130 150 170 190 210
0.8
1.2
13 14 15 16 17
1.6
2.0
