Assembly of an 80-kg tank (this is formed from the packaging).N)
6
4
5
1
2
2
7
3
4
8
Pos. Description No.
1 screw feeder tube 1
2 M8 nut 10
3 screw feeder ring 1
4 M8 washer 14
5 M8x20 bolt 6
6 tank 1
7 tank base 2
8 M8x30 bolt 4
Tank and screw feeder assemblyFig. 32
