APPENDIX D - SRM9025 HANDSET
Figure D.1 SRM9025 Handset
The Handset is arranged for connection to the RJ45 connector on the front of the SRM9000
Transceiver, either directly or via the extension lead accessory.
There are no repairable electronic components in the Handset. Only those items listed in
Paragraph D1 are replaceable. If the Handset PCB fails, the Handset must be replaced in its
entirety.
D.1 REPLACEABLE PARTS
Item Part Number
On/Off Switch tba
Volume Switch tba
Front Face Switches tba
PTT Switch tba
Curly cord tba
PWR
SND
CLR
M FCN
*
O
#
9
8
7
4
5
6
1
2
3
SEL
ABC DEF
GHI
JKL MNO
PQRS
TUV
WXYZ
.,;
