APPENDIX E - SRM9030 CONTROL HEAD
Figure E.1 SRM9030 Control Head
The Control Head is arranged for connection to the RJ45 connector on the front of the
SRM9000 Transceiver, either directly or via the extension lead accessory.
There are no repairable electronic components in the Microphone. Only those items listed in
Paragraph E1 are replaceable. If the Control Head PCB fails, the Control Head must be
replaced in its entirety.
E.1 REPLACEABLE PARTS
Item Part Number
Volume potentiometer tba
RJ45 connector tba
