5
TIGHTENING TORQUES
ELECTRICAL DIAGRAM
Description Special number in table NM Kgf.m
Head Nut 3 22 2.2
6x40 Screws 11 12 1.2
Connector 12 10 1.0
6x30 Screws 18 12 1.2
6x25 Screws 18 10 1.0
12 Nuts 28 54 5.4
12x30 Screws 32 60 6.0
8x40 Screws 39 32 3.2
Spark Plug 52 18 1.8
