16.3 IGNITION AND GENERATOR SYSTEM
Breaker-less DUCATI capacitor discharge dual ignition with magneto generator.
GENERATOR OUTPUT …………………... 170 W AC @ 6000 RPM, 13.5V RMS
AC RECTIFICATION …………………... DUCATI RECTIFIER REGULATOR
BATTERY CHARGING …………………... DUCATI RECTIFIER REGULATOR
IGNITION TIMING ……………...…… 1.96mm (18°) BTDC
SPARK PLUG …………………... NGK B9ES TWO ON EACH CYLINDER
16.4 FUEL SYSTEM:
CARBURETOR …………………. TWO BING 36 mm FOR VICTOR2PLUS,
TWO BING 38mm FOR
VICTOR2SUPER WITH CABLE
CHOKES AND AIR FILTERS
FUEL PUMP
*
…………………. MIKUNI PNEUMATIC FUEL PUMP
FUEL …………………. UNLEADED GASOLINE OR AVGAS
LUBRICATION OF ENGINE …………………. PREMIX TWO STROKE SEMI
SYNTHETIC OIL IN GASOLINE
2.5% OIL BY VOLUME TO LEADED
FUEL
3% OIL BY VOLUME TO UNLEADED
FUEL
*
ADDITIONAL ELECTRIC FUEL PUMP MAY BE REQUIRED, SEE INSTALLATION NOTES
