This section describes programming a printer port on a 4010 RS-232 card from
the front panel of the 4010 FACP.
Note: Login to the system at Access Level 4 before attempting to
program the port.
This section describes adding the RS-232 card to the 4010 job.
1. Press <MENU>.
2. Press <NEXT> or <PREVIOUS> until [PROGRAMMING] is displayed
and then press <ENTER>. The following warning appears, indicating that
the 4010 is no longer in the Fire Alarm Operation mode.
3. Press <ENTER> to continue.
4. Press <NEXT> or <PREVIOUS> until <CONFIGURE CARDS> is
displayed and then press <ENTER>.
5. Press <NEXT> or <PREVIOUS> until <ADD A 4010 CARD> is
displayed and then press <ENTER>.
6. Press <NEXT> or <PREVIOUS> until <RS232> is displayed and then
press <ENTER>. Press <ENTER> again to confirm that you want to add
an RS-232 card. A message appears indicating that the system is
configuring the card.
Press the <EXIT> key once to move back one menu level and then continue
below with Step 5 in the next section.
Use the following steps to configure the printer settings (baud rate, etc) for the
RS-232 port to which the printer is attached. Before beginning, ensure you
know the hardware settings enabled on the printer (i.e., baud rate set on printer
itself).
1. Press <MENU>.
2. Press <NEXT> or <PREVIOUS> until [PROGRAMMING] is displayed
and then press <ENTER>. A warning appears, indicating that the 4010 is
no longer in the Fire Alarm Operation mode.
3. Press <ENTER> to continue.
Continued on next page
4010 Front Panel Programming for an RS-232 Port
Introduction
Adding an RS-232 Card
Configuring RS-232 Port
Settings
Please Wait . . .
Fire Alarm Operation Suspended
Please Wait . . .
Fire Alarm Operation Suspended
To Next Page
