Simplex Flex 4100U - Amplifier Specifications

5
The specifications below apply to both analog and digital amplifiers.
Supply voltage: 19.7-31.1 VDC
Output voltage: 25 VRMS or 70.7 VRMS
Maximum output power: Flex-35 = 35 W; Flex-50 = 50 W
Flex-50
Alarm state: 5.55 A (signal) 74 mA (card)
Supervision state: 351 mA (signal) 74 mA (card)
Low power state
(NACs in supervision, no power to power stage):
0 A (signal) 85 mA (card)
Flex-35
Alarm state: 4.00 A (signal) 74 mA (card)
Supervision state: 351 mA (signal) 74 mA (card)
Low power state
(NACs in supervision, no power to power stage):
0 A (signal) 85 mA (card)
The equipment operates normally with ambient temperatures outside the cabinet from 32° to
120° F (0° to 49° C), inclusive.
The equipment operates normally under non-condensing humidity conditions up to 93% relative
humidity at 90° F (32° C).
