Features & Controls
CONTROLS
- HYDRO MODEL
4. Steering Wheel
3. Engine Throttle Control
:. Parking Brake Knob
I. Ignition Key/Switch
3. Headlight Switch
r. PTO (Electric Clutch) Switch
3. Mower Height Adjustment Lever
i. Brake Pedal
I.
Forward Direction Pedal
I. Rear Direction Pedal
Figure 2. Tractor & Mower Controls - Hydra Model
CONTROLS - GEAR MODEL
A. Steering Wheel
B. Engine Throttle Control
C. Parking Brake Knob
D. Ignition Key/Switch
E. Headlight Switch
F. PTO (Electric Clutch) Switch
G. Mower Height Adjustment Lever
H. Clutch/Brake Pedal
I. Gear Selector
Figure 3. Tractor & Mower Controls
- Gear Model
6
