Troubleshooting
&
Repair
THIS HOOK-UP FOR NEGATIVE GROUND VEHICLES
TO
TO
MAKE CERTAIN VEHICLES DO NOT TOUCH
Figure 17. Battery Jump Starting Diagram
Adjustments
‘igure 18. Seat Adjustment
A. Seat Adjustment Lever
s
L
I
F
b
/.
Nut B. Spring
BRAKE ADJUSTMENT
1. Fully depress brake pedal and lock parking brake.
SEAT ADJUSTMENT
3. See figure 19. Adjust the brake rod nut (A) until
The seat can be moved forward and back bv moving the
lever (A, figure 18) underneath the front of the seat,then
positioning the seat as desired.
spring (B) is compressed to 2-7/W
-
3” length.
21
