Page 6
Controls
SECTION CHECKLIST
Drive Control Levers
Reverse Handle
Engine Controls
DRIVE CONTROL LEVERS
Engage wheels and tines into forward, releasing returns
machine to neutral.
Pulling down on drive control levers engages the wheels
and tines. Releasing drive control levers disengages the
wheels and brings the tiller to a complete stop. It is now
in the neutral position.
CAUTION
This information is provided here only to introduce the
controls. DO NOT START THE ENGINE AT THIS TIME.
Starting and operating instructions are given on page
13. Please read this section and all operating and safety
instructions before starting your tiller.
CAUTION
ENGINE SHOULD BE OFF BEFORE ADJUSTING
ANY CONTROLS!
❖ As a safety precaution, the drive control levers
will not lock in the forward position.
❖ To stop the wheels and tines at any time, release
the drive control levers.
Drive Control Levers
Engaged
