Page 23
PROBLEM REMEDY/ACTION
Belts squeal in neutral and/or reverse
Belts squeal in forward operation
Excessive heat build up in transmission/tine area
during tilling
1. Adjust forward belt guide:
- turn engine off and allow muffler to cool
- disconnect spark plug wire from spark plug
- remove belt guard
- pull down on drive control levers
- manually bend forward belt guide so there is 1/16
inch or less clearance between belt guide and belt
- replace belt guard and spark plug wire
1. Adjust tabs on the reverse belt guide
- turn engine off and allow muffler to cool
- disconnect spark plug wire from spark plug
- release drive control levers to
neutral
- remove belt guard
- adjust tabs of reverse belt guide:
while drive control levers are released, bend metal
tabs on reverse belt guide to 1/64 inch or less
clearance from reverse belt
- replace belt guard and spark plug wire
1. Remove vegetation by following instructions in Clean
Tine Axle Shaft on page 20 of Maintenance & Storage
section. FOLLOW ALL SAFETY INSTRUCTIONS
2.Check transmission fluid and fill if needed by following
instructions on page 19
Troubleshooting and Repair
