Simplicity 1695856 User Manual

Not for
Reproduction
6
Manual Contents:
Operator Safety ..................................................................6
Safety System Tests ....................................................... 11
Features and Controls .................................................... 11
Operation ......................................................................... 12
Maintenance .................................................................... 16
Troubleshooting .............................................................. 19
The images in this document are representative, and are
meant to complement the instructional copy they accompany.
Your unit may vary from the images displayed. LEFT and
RIGHT are as seen from the operator’s position.
The spark ignition system on this snowthrower complies with
Canadian standard ICES-002.
NOTE: Please refer to the Customer Contact Guide and
Setup Instructions for additional information.
The safety alert symbol indicates a potential personal
injury hazard. A signal word (DANGER, WARNING, or
CAUTION) is used with the alert symbol to designate a
degree or level of hazard seriousness. A safety symbol may
be used to represent the type of hazard. The signal word
NOTICE is used to address practices not related to personal
injury.
DANGER indicates a hazard which, if not avoided, will
result in death or serious injury.
WARNING indicates a hazard which, if not avoided, could
result in death or serious injury.
CAUTION indicates a hazard which, if not avoided, could
result in minor or moderate injury.
NOTICE indicates an action that could result in damage to
the product.
Operator Safety
Safety Alert Symbol and Signal Words
Hazard Symbol Charts
Snowthrower Hazard Symbols
Symbol Meaning Symbol Meaning
Safety informa-
tion about haz-
ards that can
result in personal
injury.
Read and under-
stand the opera-
tor’s manual
before operating
or servicing the
unit.
Amputation
hazard - rotating
impeller.
Remove the key
before perform-
ing service.
Amputation
hazard - rotating
impeller.
Amputation
hazard - rotating
auger.
Amputation haz-
ard - do not touch
moving parts.
Thrown objects
hazard.
Fire hazard. Explosion haz-
ard.
Shock hazard. Toxic fume haz-
ard.
The following products are covered by this manual:
Products Covered by This Manual
1695856
1695994
1695995
1695996
1695996-00
1695996-01
1695996-02
1695997
1695997-00
1695997-01
1695997-02
1696009
1696010
1696011
1696011-00
1696011-01
1696011-02
1696012
1696012-00
1696012-01
1696012-02
1696053
1696054
1696055
1696055-00
1696055-01
1696056
1696061
1696062
1696062-00
1696062-01
1696063
1696065
1696066
1696067
1696199-00
1696199-01
1696200-00
1696201-00
1696201-01
1696202-00
1696202-01
1696203-00
1696203-01
1696206-00
1696207-00
1696207-01
1696212-00
1696212-01
1696220-00
1696221-00
1696221-01
1696222-00
1696222-01
1696223-00
1696223-01
1696224-00
1696224-01
1696226-00
1696227-00
1696227-01
1696228-00
1696229-00
1696230-00
1696253-00
1696253-01
1696254-00
1696254-01
1696255-00
1696255-01
1696256-00
1696256-01
1696257-00
1696257-01
1696277-00
1696278-00
1696300-00
1696301
1696301-00
1696302-00
1696381-00
1696382-00
1696390-00
1696391-00
1696392-00
1696481-00
1696482-00
1696483-00
1696484-00
1696485-00
1696486-00
1696487-00
1696488-00
1696489-00
1696490-00
1696491-00
1696493-00
1696494-00
1696495-00
1696522-00
1696523-00
1696524-00
