C-10
Mower deck removal
The muffler and surrounding areas may be hot.
1. Park tractor on a hard, level surface such as a concrete floor.
Move the PTO switch (B) and ignition switch (E) to the
off position, remove the key, depress the brake pedal (D)
and apply parking brake (C).
2. Disconnect the discharge tube (G) from the mower deck.
3. Place the mower deck lift lever (A) in the lowered position.
4. Place mower deck in the lowest cutting position using the
cutting height adjust (F).
(procedure continues)
G
A
B
E
D
C
F
