PART NO. DESCRIPTIONREF NO. QTY.
Engine & PTO Group - Kohler (276engk0)
Footnotes
PLATE, CLUTCH ANCHOR 1 5061857CSM 1
CLUTCH ANCHOR PAD 2 5043636SM 1
WASHER, .34 X 1.25 X 10 GA 3 5044617SM 3
BOLT, 5/16-18 X 1" GD5 YZ 4 5025011X8SM 5
NUT, 5/16-18 HEX NYLOCK FLANGE 5 5025392SM 6
WASHER, 5/16" SAE 6 5025155SM 3
KEY, 1/4" SQ. X 2 1/4 7 5050407X18 1
SPACER, .45 X 1.62 X .37 8 5042132SM 1
BOLT, CRANKSHAFT, 7/16-20 X 3-1/4" 9 5023253SM 1
CLUTCH, # 51110100,ELECTRIC, 1" SHAFT 10 5023100SM 1
BOLT, 5/16-18 X 2-1/4" GD5 YZ 11 5025011X18 1
HOSE, OIL DRAIN 12 5048681SM 1
ENGINE, 20HP KOHLER COURAGE 13 * 1
BOLT, 3/8-16 X 1", SELF-TAPPING 14 5100399SM 3
CLAMP, VINYL INSULATED 15 5021500SM 1
BOLT, 1/4-20 X 3/4" GD5 YZ 16 5025010X6SM 1
NUT, 1/4-20 HEX SERR. FLANGE 17 5025126SM 1
WASHER, 5/16" INT. TOOTH LOCK 18 5025188SM 1
Note * See your local Kohler distributor for parts and service.
The above parts group applies to the following Mfg. Nos.:
13
2009Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
2690449 - Cham
ion
2690483 - Champion
TP 400-7276-N-CH-S
