Transmission Drive & Carrier Group — Peerless Model MST 205-515A Transaxle
9
TP 400-2247-02-EX-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693452 Express, 14.5HP Gear
1693586 Express, 14.5HP Gear (Export)
1693666 Express, 14.5HP Gear (Export)
1693732 Express, 14.5HP Gear (Export)
1 1720619 1 TRANSMISSION ASSEMBLY
2 1716103 2 ANCHOR, Torsion Bar
3 960551 6 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 2-1/2
4 1927557 2 NUT, Hex, Flange Whiz Lock, 5/16-18
5 1919381 2 WASHER, 5/16
6 1930601 2 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 5/8
7 1715043 2 SPACER (Domestic Models)
8 927794 2 E-RING (Domestic Models)
9 960202 4 WASHER, 3/4 (Domestic Models)
10 905123 1 KEY, Woodruff #9 (Domestic Models)
11 1714764 1 PULLEY ASSEMBLY
12 927103 1 RING, Retaining
13 1664789 1 V-BELT, HA
14 1717749 2 KEY
15 1928703 1 SPEED NUT, “U” Type, #14A
16 1920415 1 CAPSCREW, Hex Hd, 3/8-16 x 1-1/4
17 1924940 2 WASHER, Plain, 3/8 (Domestic Models)
18 1719595 1 GUIDE, Belt
19 1916965 1 LOCKWASHER, 3/8
20 1916950 1 NUT, Hex, Full, 3/8-16
21 1713843 1 KNOB, Plastic, Gear Shift
22 1719762 1 ROD, Shift
23 156302 1 SPRING, Gear Shift
24 1918448 2 PIN, Cotter, 3/32 x 1
25 1960027 2 WASHER, 1/2
26 1714536 2 PULLEY HALF, Engine PTO (Gear Models)
27 1931333 1 CARRIAGE BOLT, 5/16-18 x 3/4
28 1917372 2 NUT, Hex, Full, 5/16-18
29 1917356 1 LOCKWASHER, 5/16
30 1720293 1 GUARD, Belt
31 1919438 5 NUT, Hex Nylon Lock, 5/16-18
32 1919326 2 WASHER, Plain, 5/16
33 1719824 1 SPRING, Compression
34 1719825 1 SPRING, Compression
35 1714767 1 ROD, Brake
36 1918447 1 PIN, Cotter, 3/32 x 3/4
37 1678341 1 SPRING, Return
38 1960223 3 CARRIAGE BOLT, 5/16-18 x 1-1/4
39 1663114 2 BUSHING, Plastic, 5/8
40 1660365 1 BELLCRANK ASSY
41 921133 1 FITTING, Grease
42 1924940 1 WASHER, Plain, 3/8
43 1921965 1 CAPSCREW, Hex Hd., 3/8-16 x 3/4
44 1715028 1 LINK, Shift, Lower
45 1960555 1 CARRIAGE BOLT, 5/16-18 x 1-1/2
46 1714556 1 LEVER, Shift
47 1921319 1 WASHER, Plain, 1/4
48 1916964 1 LOCKWASHER, 1/4
49 1922234 1 CAPSCREW, Hex Hd, 1/4-28 x 5/8
50 1715029 1 LINK, Shift, Upper
