TP 400-2247-02-EX-SMA
38” Mower Decks - Housing, Arbors & Blades
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693464 38” Mower Deck
1693588 38” Mower Deck (Export)
1 1705449 1 DEFLECTOR, Plastic
2 1960518 2 NUT, Push On
3 1705249 2 SPACER (Export Models Only)
4 1960353 3 WASHER, 1/4 (Export Models Only, Qty 1)
5 1704873 1 CLAMP
6 1919326 1 WASHER, Plain, 5/16
7 1705080 1 SPRING
8 1916964 2 LOCKWASHER, 1/4
9 1916622 2 NUT, Hex, 1/4-20
10 1713616 2 HUB
11 1720388 1 PULLEY, Deck Drive, R.H. 5.25
12 1714322 2 STOP, Belt, R.H.
13 1927557 2 NUT, Hex, Flange Whiz Lock, 5/16-18
14 1713675 4 WASHER, Belleville
15 1714419 2 NUT, Hex, Flange, 9/16-8
16 1713199 2 COVER, Arbor Housing
17 1713204 2 SPACER
18 1705897 4 BEARING
19 1707335 2 GASKET, Foam
20 1713198 2 HOUSING ARBOR, Bottom
21 1704314 2 FITTING, Grease
22 1713338 2 ARBOR HOUSING ASSEMBLY (Incl. Fitting Ref. 21)
23 1706709 1 ROD, Deflector, Front
24 1705115 2 PLUG, Plastic
25 1960633 2 CARRIAGE BOLT, 1/4-20 x 1 1/2
26 1720387 1 PULLEY, Deck Drive, L.H. 4.0
27 1714321 1 STOP, Belt, L.H.
28 1924940 2 WASHER, Plain, 3/8
29 1664847 3 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 3/4
30 1721143 1 COVER & SUPPORT ASSEMBLY, Arbor L.H. (Export Models Only)
31 41721160 1 HOUSING ASSEMBLY, 38” Mower (Cardinal Red)
32 1960373 12 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 1
33 1713619 2 WASHER
34 1713612 2 SHAFT, Arbor
35 1713196 2 SHIELD, Grass, Lower
36 1704856 1 BLADE, Mower, 16-1/8”
37 1713089 2 WASHER, Hex
38 1656916 2 WASHER, Spring
39 923471 2 CAPSCREW, Hex, Hd., 7/16-14 x -1/4
40 1704101 1 BLADE, Mower, 22-1/4”
41 1931333 4 CARRIAGE BOLT, 5/16 - 18 x 3/4 G5
42 1715817 1 BAFFLE, Anti-Blowout (Export Models Only)
43 1935048 4 NUT, Hex Flange Lock, 5/16-18
44 1721142 1 COVER & SUPPORT ASSEMBLY, Arbor R.H. (Export Models Only)
To Next Page
