39
TP 400-2247-02-EX-SMA
38” Mower Decks - Height Adjustment
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693464 38” Mower Deck
1693588 38” Mower Deck (Export)
1 1931353 1 CARRIAGE BOLT, 3/8-16 x 1-3/4
2 1717658 1 ADJUSTMENT ARM
3 1714876 1 GRIP
4 910542 2 RIVET
5 1716028 1 SPRING, Handle
6 1664847 4 CAPSCREW, Hex Washer Hd, Taptite, 5/16 - 18 x 3/4
7 1714910 1 BRACKET, Upstop
8 1714263 1 SPRING
9 1930645 2 NUT, Hex Flange Whiz Lock, 3/8-16
10 1719792 1 BRACKET, “U”
11 1960223 1 CARRIAGE BOLT, 5/16-18 x 1-1/4
12 1665374 1 STRAP
13 1916950 1 NUT, Hex, Full, 3/8-16
14 1916965 1 LOCKWASHER, 3/8
15 1704082 1 NUT, Adjuster
16 1931352 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
17 1714327 1 ROCKER ARM ASSEMBLY
18 1923362 4 NUT, Hex Lock, 5/16-18
19 1960236 4 SPACER
20 1960044 8 WASHER, 5/16
21 1921333 2 CAPSCREW, Hex Hd, 5/16-18 x 1
22 1960373 2 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 1
23 1921977 2 CAPSCREW, Hex Hd, 5/16-18 x 1-1/4
24 1710703 2 SPACER
25 1960074 1 CLIP, Spring
26 1714529 1 ROD, Transport
27 1717297 1 ARM, Rear
28 1714879 1 ECCENTRIC
29 1924874 1 WASHER, Flat, 5/16
30 1917356 1 LOCKWASHER, 5/16
31 1917372 1 NUT, Hex, Full, 5/16-18
32 1923701 1 CAPSCREW, Hex Hd., 3/8-16 x 2, Grade 5
33 1715024 1 SPACER
34 1924940 4 WASHER, Plain, 3/8
35 1721081 1 ARM, Pitch
36 1611705 1 SPACER
37 1714877 2 ARM ASSEMBLY
38 1714760 2 GAUGE WHEEL
39 1960027 2 WASHER, 1/2
40 158399 2 RETAINING RING
41 1960594 1 CAPSCREW, Hex Washer Hd, Taptite, 5/16 - 18 x 7/8
