41
TP 400-2247-02-EX-SMA
44” Mower Decks - Housing, Arbors & Blades
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693527 44” Mower Deck
1693591 44” Mower Deck (Export)
1 1714419 3 NUT, Hex, Flange, 9/16-8
2 1713675 6 WASHER, Belleville
3 1713161 3 PULLEY, R.H. Arbor, Center Arbor & L.H. Arbor
4 1713616 3 HUB, Adapter (R.H., Center & L.H.)
5 1655729 3 COVER, Arbor Housing
6 108202 3 BEARING, Upper
7 1715724 3 SPACER, Sleeve, Upper Bearing
8 1715723 3 SPACER, Arbor, Internal
9 1705897 3 BEARING, Lower
10 1707335 3 GASKET, Foam
11 1713338 3 ARBOR HOUSING ASSEMBLY (Incl. Fitting Ref. 12)
12 1704314 3 FITTING, Grease
13 1720659 1 UP-STOP, 5 1/4 High
14 1960373 18 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 1
15 1664847 11 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 3/4
16 1720560 2 COVER, Arbor
17 1919381 4 WASHER, 5/16
18 1713619 3 WASHER
19 1713612 3 SHAFT, Arbor (R.H., Center & L.H.)
20 1713196 3 SHIELD, Grass, Lower
21 1704100 3 BLADE, Mower
22 1713089 3 WASHER, Hex
23 1656916 3 WASHER, Spring
24 923471 3 CAPSCREW, Hex, Hd., 7/16-14 x 1-1/4
25 1716879 1 BAFFLE, Blowout, L.H. (Export Only)
26 1930600 2 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 1 1/2
27 1931333 8 CARRIAGE BOLT, 5/16-18 x 3/4 (Export Only)
28 1935048 8 NUT, Hex Flange 2-Way Lock 5/16-18 (Export Only)
29 1716878 1 BAFFLE, Blowout R.H. (Export Only)
30 41721165 1 HOUSING ASSEMBLY, (Cardinal Red)
31 1931318 2 CARRIAGE BOLT, 1/4-20 x 7/8 (Domestic Only)
32 1960518 2 NUT, Push On
33 1960353 5 WASHER, Plain, 1/4
34 1704873 1 CLAMP
35 1919326 1 WASHER, Plain, 5/16
36 1705080 1 SPRING, Deflector Retaining
37 1916964 2 LOCKWASHER, 1/4
38 1916622 2 NUT, Hex, 1/4-20, UNC
39 1706709 1 ROD, Deflector, Front
40 1705115 1 PLUG, Hole
41 1705449 1 DEFLECTOR, Plastic
42 1924940 2 WASHER, 3/8
43 1927557 2 NUT, Hex FlangeWhiz Lock, 5/16-18
44 1704099 1 BELT STOP, Center
To Next Page
