TP 400-2247-02-EX-SMA
44” Mower Decks - Clutch & Support
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693527 44” Mower Deck
1693591 44” Mower Deck (Export)
1 1719911 1 V-BELT
2 1924940 13 WASHER, 3/8
3 1719933 3 SUPPORT, Brake Actuator
4 1927557 6 NUT, Hex Flange Whix Lock, 5/16
5 1719419 3 ACTUATOR & PAD ASSEMBLY, Brake
6 1960607 3 PIN, Clevis, 3/4 Hd
7 1918447 3 COTTER PIN
8 1719944 1 ROD, Brake R.H.
9 1719526 3 SPRING
10 1960339 3 NUT, Hex Flange Whix Lock, 3/8
11 1719936 1 RETAINER, Belt
12 1720630 1 IDLER ARM ASSEMBLY, with Bushings
13 1667811 1 SPACER
14 171247 1 PULLEY ASSEMBLY, Idler
15 1923701 1 CAPSCREW, Hex Hd, 3/8-16 x 2
16 1918451 1 COTTER PIN
17 1960074 1 CLIP, Hair Pin
18 1720540 1 ROD, 2 Bends
19 1719777 1 COLLAR, Set
20 1928721 1 SET SCREW, Square Hd Cup Point, 5/16-18 x 1/2
21 1720462 1 SPRING
22 1921210 1 CAPSCREW, Hex Hd, 3/8-16 x 1
23 1719539 1 GUIDE, C
24 108717 1 SPACER
25 1676148 2 BUSHING
26 912808 2 FITTING
27 1719943 1 ROD, Brake L.H.
28 1657242 1 SPACER
29 1720539 1 ROD, Brake Center
30 1924356 2 WASHER, 3/8
31 1928957 1 CAPSCREW, Hex Hd, 3/8-16 x 2 3/4
32 1919439 2 NUT, Hex Nylon Lock, 3/8-16
33 157081 2 SPACER
34 1919384 1 WASHER, 3/8
35 1713578 1 ROD, Mower Hitch
36 1715759 1 ROD, Latch
37 1921969 2 CAPSCREW, Hex Hd, 3/8-16 x 1-1/2
38 1713561 1 HITCH
39 1960519 1 NUT, Push, 1/2
40 156302 1 SPRING
To Next Page
