TP 400-2247-02-EX-SMA
44” Mower Decks - Height Adjustment
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693527 44” Mower Deck
1693591 44” Mower Deck (Export)
1 1664847 8 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 3/4
2 1714910 1 BRACKET, “L”
3 1921977 2 CAPSCREW, Hex Hd, 5/16-18 x 1-1/4
4 1960044 8 WASHER, 5/16
5 1719792 1 BRACKET, “U”
6 1710703 2 SPACER
7 1923362 4 NUT, Hex Lock, 5/16-18
8 1960074 1 CLIP, Spring
9 1714529 1 ROD, Transport
10 1717145 1 ARM, Rear
11 1960223 1 CARRIAGE BOLT, 5/16-18 x 1-1/4
12 1714876 1 GRIP
13 910542 2 RIVET
14 1716028 1 SPRING, Handle
15 1717658 1 ARM, Adjustment (includes ref. 13 & 14)
16 1931353 1 CARRIAGE BOLT, 3/8-16 x 1-3/4
17 1714263 1 SPRING
18 1930645 2 NUT, Hex Flange Whiz Lock Two Way, 3/8-16
19 1917372 2 NUT, Hex, Full, 5/16-18
20 1917356 2 LOCKWASHER, 5/16
21 1921332 1 CAPSCREW, Hex Hd, 5/16-18 x 3/4
22 1717109 1 QUADRANT
23 1715671 1 ARM ASSEMBLY, Rocker
24 1665374 2 STRAP
25 1714879 1 ECCENTRIC
26 1924874 1 WASHER, 5/16
27 1916950 1 NUT, Hex, 3/8
28 1916965 1 WASHER, Lock, 3/8
29 1704082 1 NUT, Adjuster
30 1931352 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
31 1960373 4 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 1
32 1960594 1 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 7/8
33 1960236 4 SPACER
34 1921333 2 CAPSCREW, Hex Hd, 5/16-18 x 1
35 158399 4 E-RING, 1/2
36 1960027 4 WASHER, 1/2
37 1714760 5 WHEEL, Gauge
38 1714877 2 ARM ASSEMBLY
39 1715608 2 STRAP
40 1714881 1 BRACKET, Gauge Wheel
41 1715624 1 ROD, Mower Hitch
42 1960519 1 NUT, Push, 1/2
43 1924940 4 WASHER, 3/8
44 1611705 1 SPACER
45 1718019 1 ARM, Pitch
46 1715024 1 SPACER
47 1923701 1 CAPSCREW, Hex Hd, 3/8-16 x 2, Grade 5
