7
TP 400-2247-02-EX-SMA
Engine - 14.5HP, 15.5HP & 17HP B&S Intek
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
* Obtain repair parts from your local Briggs & Stratton Distributor.
** Replaced by Reference 9.
The above parts group applies to the following Mfg. Nos.:
1693452 Express, 14.5HP Gear
1693586 Express, 14.5HP Gear (Export)
1693666 Express, 14.5HP Gear (Export)
1693732 Express, 14.5HP Gear (Export)
1693458 Express, 15.5HP Hydro
1693589 Express, 15.5HP Hydro (Export)
1693668 Express, 15.5HP Hydro (Export)
1693734 Express, 15.5HP Hydro (Export)
1693525 Express, 17HP Hydro
1693641 Express, 17HP Hydro (Export)
1693670 Express, 17HP Hydro (Export)
1693736 Express, 17HP Hydro (Export)
1 1720040 1 SHIELD, Muffler Side
2 1720039 1 SHIELD, Muffler Top
3 1960001 2 CAPSCREW, Hex Washer Hd, Plastite, #10 - 14 x 5/8
4 1924856 1 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 1/2
5 * 1 ENGINE, 14.5HP B&S INTEK
5 * 1 ENGINE, 15.5HP B&S INTEK
5 * 1 ENGINE, 17HP B&S INTEK
6 920427 1 LOCKWASHER, External Tooth, 3/8
7 916950 1 NUT, Hex, 3/8-16 NC-2B
8 1931648 2 CAPSCREW, Whiz Lock Hex Hd, 5/16-18 x 1/2
9 1721131 1 BAFFLE, Heat
10 173206 1 FUEL FILTER
11 1960112 2 HOSE CLAMP
12 1657575 1 HOSE, Fuel, 1/4 ID x 1/2 OD x 12
13 1719768 1 KNOB, Throttle (Red)
14 1960498 2 CAPSCREW, Plastite Hex Washer Hd, 1/4-10 x 5/8
15 1707388 1 CONTROL, Throttle
16 1719456 1 PULLEY (with Hub)
17 1933263 3 WASHER, 7/16
18 930598 3 CAPSCREW, Hex Washer Hd, Taptite, 3/8-16 x 1-1/2
19 1719460 1 GUIDE, Belt
20 1960370 1 CAPSCREW, Hex Hd, 7/16-20 x 2-1/2
21 1918199 1 LOCKWASHER, 7/16
22 960361 1 CAPSCREW, Hex Washer Hd, Taptite, 3/8-16 x 2
23 1719458 1 MUFFLER ASSEMBLY
24 1719961 1 SCREEN, Exhaust
25 1720037** 1 BAFFLE, Heat
26 1960034** 1 CAPSCREW, Plastite Hex Washer Hd, #10-14 x 1/2
27 1720046** 1 BAFFLE, Engine, LH
