33
Regular Maintenance
Grease the Electric
Lift Rod Grease
Fitting Yearly
Grease the Deck Belt Idler Pulley
Arm Grease Fitting Yearly
48” Mower
60” Mower
54” Mower
Figure 41. Mower Drive ShaftFigure 40. Mower Arbor Lubrication
Figure 39. Deck Lubrication
Every 10 Hours
Not for
Reproduction
