Page #3 background imageLoading...
Page #3 background image
Champion Series
9/2003 3
TP 300-3883-02-CH-SN
Quick Setup List -
Page Setup Procedure Steps to Perform
4 Uncrating Remove crate & banding.
Place transmissions in PUSH position & roll off skid.
4 Battery Activation & Charge the battery
(Note: proceed with other setup steps
Installation
while battery is charging).
Test battery with hydrometer or load-tester.
Install & secure battery.
5 Rider Assembly Install the seat and connect the seat switch
Install ground speed control levers.
6 Check Fluid Levels Fill & check Engine oil level.
Check transmission fluid level.
Reduce & check tire pressures
(Front tires 40 psi, rear tires 15 psi).
7 Mower Assembly Torque mower blade bolts.
7 Lubrication Lubricate all grease & oil points.
8 SAFETY CHECKS Check for LOOSE HARDWARE.
Check all OPERA
T
OR CONTROLS.
Test P
ARKING BRAKE.
Perform MO
WER BLADE STOPPING CHECK.
(Blade must stop within 5 seconds!)
Perform SAFETY INTERLOCK SYSTEM CHECK.
9 Burnish Electric Clutch Burnish electric clutch
(run for 15 seconds, repeat 10 times)
.
Repeat MO
WER BLADE STOPPING CHECK.
(Blade must stop within 5 seconds!)
