42” Snow Plow/Dozer Blade
5. Raise the push bar and hook up the spring (A, fig-
ure 6) in location
B or C as follows:
Location
B
Tractor (Series)
4000,5000,500,600,
12LT. 12RT. Resent
I
C
I
6000,800,
16GTH, 17GTH
I
6. Lower the push bar and tighten the capscrew and
nut which hold chain to tractor frame.
gure 6. Lift-Assist Spring
Spring
Spring Location-Lawn Tractors (See Chart)
Spring Location - Garden Tractors (See Chart)
