Simplicity ZT Series - Wide Body Cart, Tube & Hitch Group Parts List

19
TP 400-2209-00-AT-SMA
Wide Body Cart, Tube & Hitch Group - 1693108
1 1705063 1 CLIP, Spring
2 1707712 1 TUBE ASSY, Lower
3 1704854 1 TUBE ASSY, Middle
4 1707710 1 TUBE ASSY, Upper
5 1960252 2 CARRIAGE BOLT, 1/4-20 x 5/8
6 1930641 2 LOCKNUT, Flange, 1/4-20
7 1930531 6 SCREW, Truss Head, 10-32 x 1/2
8 1910531 12 WASHER, Plain, #10
9 1928919 6 NUT & WASHER ASSY, 10-32
10 1921210 1 Capscrew, 3/8-16 x 1
11 1924940 2 Flat Washer, 3/6
12 1666332 2 Spacer
13 1703334 1 Hitch
14 1916965 2 Lockwasher, 3/8
15 1922130 2 Capscrew, 3/8-16 x 2-1/4
16 1930561 1 Hex Nut, 3/8-16
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693108, Wide Body Dump Cart
