Simplicity ZT Series - Clean Sweep Twin Bag Grass Catcher; Adapter, Blade, & Tube Group Parts List

21
TP 400-2209-00-AT-SMA
Clean Sweep Twin Bag Grass Catcher; Adapter, Blade, & Tube Group - 1693150
1 1679163 1 WING NUT ASSY.
2 1702665 2 SPACER
3 1703765 1 BAFFLE, 38” Mower
4 1703769 1 TUBE, Transfer
5 1718535 1 ADAPTER
6 1704341 1 WASHER, Special
7 1704355 1 BRACKET, Attachment
8 1704603 1 LATCH, Tube
9 1704977 1 BLADE, High Lift, 38” Mower
10 1705010 1 ADAPTER, Blade, High Lift
11 1917356 4 LOCKWASHER, 5/16
12 1917372 4 NUT, Hex, 5/16-18
13 1919326 1 WASHER, Flat
14 1919438 3 NUT, Hex, Lock Esna, 5/16-18
15 1928698 1 NUT, Hex, Centerlock, 5/16-18
16 1931332 1 CARRIAGE BOLT, 5/16-16 x 5/8
17 1931338 2 CARRIAGE BOLT, 5/16-18 x 1 -3/4
18 1931339 1 CARRIAGE BOLT, 5/16-18 x 2
19 1935048 1 NUT, Flange Lock
20 1960122 1 CAPSCREW, Hex Hd.
21 1960185 1 WASHER, Flat
22 1960371 3 CAPSCREW, Hex Hd., 5/16-18 x 3/4
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693150, Clean Sweep Catcher
