Simplicity ZT Series - Turbo Clean Sweep Twin Catcher, Tube Group Parts List

27
TP 400-2209-00-AT-SMA
Turbo Twin Catcher, Tube Group - 1693151
1 910542 2 RIVET, Pop
2 1715663 1 ELBOW, Upper
3 1705063 1 CLIP, Spring
4 1705111 1 TUBE ASSY., Lower (Incl. Ref. Nos.1, 3 & 5)
5 1910531 6 WASHER, Plain
6 1928919 2 NUT, Hex
7 1930531 2 SCREW, Truss Hd., #10-32 x 1/2
8 1930641 1 NUT, Hex, Flange Lock, 1/4-20 (Shipped with Turbo )
9 1960252 1 CARRIAGE BOLT, 1/4-20 x 5/8 (Shipped with Turbo )
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693151, Turbo Clean Sweep Twin Bag Grass Catcher
