31
TP 400-2209-00-AT-SMA
38” Turbo , Mounting Group - 1693225
1 1916965 1 LOCKWASHER, 3/8
2 1916950 1 NUT, 3/8-16
3 1705141 1 V-BELT
4 1705066 1 PIVOT BRACKET
5 1931277 3 LOCKNUT, 5/16-18
6 1960404 4 SCREW, Truss Hd., 10-24 x 3/4
7 1933896 4 NUT, Nylock, 20-24
8 1718295 1 SUPPORT ROD, Deflector
9 1917372 4 NUT, 5/16-18
10 1917356 4 LOCKWASHER,
11 1714817 1 IDLER PULLEY ASSY. (Includes Spacer)
12 1715018 1 SPRING LATCH
13 1923362 1 LOCKNUT, 5/16-18
14 1670578 1 KNOB
15 1933468 1 WASHER, 11/32 OD x 1-1/4 ID x 1/8 Thick
16 1931337 1 CARRIAGE BOLT, 5/16-18 x 1-1/2
17 1713624 1 HUB, Splined, 1.28” Long
18 1713091 1 PULLEY
19 1713621 1 HUB, 1.65” Long
20 1704881 1 BAFFLE
21 1930600 2 SCREW, Taptite, 5/16-18 x 1-1/2
22 1931333 2 CARRIAGE BOLT, 5/16-18 x 3/4
23 1717143 1 BRACKET, Counterbalance
24 1930591 1 SCREW, Hex Whiz-Lock, 5/16-18 x 3/4
25 1716875 1 SPRING, Compression (Long)
26 1717289 1 ROD ASSEMBLY, Counterbalance
27 1935048 1 NUT, Flange, 2-Way Lock, 5/16-18
28 1917356 1 LOCKWASHER, 5/16
29 1960233 1 CARRIAGE BOLT, 5/16-18 x 1-1/4
30 1717297 1 ARM, Rear
31 1718215 1 LEVER ASSEMBLY, ZT Counterbalance
32 1718214 1 SPRING, Compression (Short)
33 1921971 1 CAPSCREW, 3/8-16 x 1-1/4
34 1924940 2 WASHER, 3/8
35 172845 1 BELT GUIDE
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693225, 38” Turbo
