33
TP 400-2209-00-AT-SMA
50” Turbo, Blower Group - 1693228
1 1935048 6 NUT, Flange, Whizlock, 5/16-18
2 1960252 1 CARRIAGE BOLT, 1/4-20 x 5/8
3 1920397 9 NUT, Hex, Nylock, 1/4-20
4 1930641 3 NUT, Hex, Flange Lock, 1/4-20
5 1921959 3 CAPSCREW, Hex, 1/4-20 x 5/8
6 1705267 1 PLATE, Cover
7 1931333 9 CARRIAGE BOLT, 5/16-18 x 3/4
8 1960472 2 SCREW, Truss Hd., 1/4-18 x 5/8
9 1931355 1 CARRIAGE BOLT, 3/8-16 x 2-1/4
10 1678435 1 BELT STOP
11 1924874 1 WASHER, Flat
12 1917356 1 WASHER, Spring Lock, 5/16
13 1917372 1 NUT, Hex, 5/16
14 1924361 1 WASHER, Flat
15 1676148 2 BUSHING
16 1704314 1 FITTING, Grease
17 1668500 1 BRACKET, Anchor, Spring
18 1923341 3 CAPSCREW, Hex Hd., 1/4-20 x 3/4 (38” Models)
19 1716853 1 SPRING, Tension
20 1704983 1 BRACKET ASSY., Turbo
21 1920415 1 CAPSCREW, Hex Hd., 3/8-16 x 1-1/4
22 1924940 2 WASHER, Plain
23 1708030 1 IDLER PULLEY ASSY.
24 1933263 1 WASHER, Flat
25 1960251 2 NUT, Hex, Jam, Center Lock, 3/8-16
26 1924940 1 WASHER, Flat
27 1706284 1 LEVER ASSY, Turbo (Incl. Ref. Nos. 15 &16)
28 1676833 1 SPACER
29 1706634 1 PULLEY, Driven
30 1928691 1 SETSCREW, Hex, Socket Hd., 5/16-18 x 5/16
31 1706465 1 PLATE ASSY.
32 960403 1 KEY, Woodruff, Modified
33 1924009 1 CAPSCREW, Hex Hd., 1/4-20 x 7/8 (44” Models)
34 1700259 1 DECAL, Danger, Blower
35 1665982 4 BEARING, Retainer
36 108202 2 BEARING
37 1933988 3 PUSH NUT, 3/8
38 1706631 1 FAN ASSY., 5 Blade
39 1960256 1 SCREW, Truss Hd.., 1/4-18 x 1/4
40 1705492 1 FAN HOUSING (Incl. Ref. No. 34)
41 1925003 1 CAPSCREW, Hex, Taptite, 1/4-20 x 1/2
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693228, 50” Turbo
