ASSEMBLY
STEP 3
STEP 4
4
1. Use Phillips Screwdriver to attach Handle 4 to Drawer Front O .
1
3
1. Align Drawer Back Q with Drawer Bottom R and press firmly into slot .
2. Attach back using 2 Allen Key Screws 1 through guide holes on each side.
3. Use Allen key 3 to tighten. Do not over tighten.
NOTE: The screwdriver is not
included in the hardware pack.
O
11/23
Q
R
O
PL
PR
MODEL # AXCRCOS72-MAH
