SIMPLIHOME COSMOPOLITAN - Internal Structure Assembly Steps; Attaching Dividers and Shelves

ASSEMBLY
12/23
1. Insert 6 Dowels 12 into Centre Shelf E .
2. Use rubber mallet to tap Dowels 12 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Align Dowels 12 with guide holes and attach Middle Divider GL , GR .
STEP 6
1. Attach 6 Cam Lock Pins 2 to Top Shelf D .
2. Align Cam Lock Pins with guide holes and attach Middle Dividers GL , GR .
3. Insert 3 Cam Lock 2 into guide holes on each Middle Divider GL , GR .
4. Use flathead screwdriver to secure Cam Lock.
5. Use 3 Allen Key Screws 1 attach Top Shelf D to Top Divider F .
STEP 5
