ASSEMBLY
STEP 7
13/23
1. Insert 2 Dowels 12 into each Divider HL , HR & GL , GR .
2. Use rubber mallet to tap Dowels 12 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Align Dowels 12 with guide holes and attach Bottom Shelf C .
4. Use 12 Allen Key Screws 1 attach Bottom Shelf C to Dividers HL , HR & GL , GR .
E
D
F
2
1. Attach 3 Cam Lock Pins 2 to each Divider HL , HR .
2. Align Cam Lock Pins guide holes and attach Top Shelf D .
3. Insert 6 Cam Lock 2 into guide holes on Top Shelf D .
4. Use flathead screwdriver to secure Cam Lock.
STEP 8
GR
GL
HL
HR
Fro
n
t
/ Av
an
t
F
r
o
nt / Ava
n
t
Fr
ont
/
A
v
a
n
t
Fron
t
/ Av
a
n
t
F
r
ont /
A
v
an
t
F
ront / A
va
n
t
F
r
o
nt / Avan
t
Fron
t
/
Av
an
t
Fr
ont
/
A
v
a
n
t
F
ro
nt / Ava
n
t
F
ro
nt /
Av
a
nt
GR
HR
GL
HL
C
12
1
3
MODEL # AXCRCOS72-MAH
To Next Page
