Step 10
NOTE: The screwdriver is not
included in the hardware pack.
4
B
L
L
L
R
Front /
Avant
Front /
Avant
1. Attach Back Panels LL , LR to back frame of medium storage using twenty three
Phillips Screws Round Head 4 through guide holes.
2. Use Phillips Screwdriver to tighten screws. Do not over-tighten.
Warning Label
18
Model # AXCHRP-06-TKAssembly
