Step 9
1
3
7
D
B
1
3
A
L
A
R
Front /
Avant
Front / Avant
Front /
Avant
Front / Avant
Front / Avant
1. Insert two Wood Dowels 7 into guide holes on each Side AL , AR .
2. Use rubber mallet to tap Wood Dowels 7 into bottom of holes securely.
1/2 length of Dowels should be exposed.
3. Attach Top B to Sides AL , AR and Divider D using nine Allen Key Screws 1
(three screws on each Side and Divider).
4. Use Allen Key 3 to tighten Screws. Do not over-tighten.
17
Model # AXCHRP-06-TKAssembly
