Simpson Lawrence Pacific C1250 - Detailed Parts List

3
1.3 PARTS LIST
Item Part No. Part Description Quantity
C1250 C1250
Anchoring Anchoring
2 P103064 Shim Bearing - Main 1
3 P103036 Shim Bearing - Gears 1
4 P103037 Shim W asher - Drum 1
5 P106003 Drum 1
6 P106200 Cap - T op 1
7 P106210 Cap - Inner Seal 1
8 P106215 Cap - Lock 1
9 P109003 Deck Housing 1
10 P109301 Deck Clamp 1
11 P154000 Stud 6
12 P339017 Nut 6
13 P342000 O Ring 1
15 P342050 O Ring 1
16 P342435 O Ring 1
17 P354101 Screw 6
18 P354014 Screw 6
19 P354231 Screw 1
22 P366042 Washer 1
23 P366045 Washer 6
24 P418201 Gearset (Complete) 1
24a - Gearset (Complete) -
25 P418100 Grease Nipple 1
26 P336040HMS Motor 12V 1
26a P336041HMS Motor 24V 1
27 P118012 Pinion 1
27a - Pinion -
28 P303104 Spragg Clutch 1
30 P354325 Screw 4
31 P113020 Key 1
32 P342030 O Ring 1
33 P136007 Flange 1
