FASTENERS AND FUEL CELLS FOR GCN TOOLS
SELECTING FASTENERS AND FUEL CELLS
GDP Collated Pins (GCN-MEP tool requires GCN-MEPMAG)
Model No. Description Qty Pins/ pack +1 Fuel Cell Compatible Gas-Actuated Nailer
GDP-50KT .106 dia. x ½" pin 1,000 GCN150, GCN-MEP, TF1100, C3, C4
GDP-562KT .106 dia. x
5
⁄8" pin 1,000 GCN150, GCN-MEP, TF1100, C3, C4
GDP-75KT .106 dia. x ¾" pin 1,000 GCN150, GCN-MEP, TF1100, C3, C4
GDP-100KT .106 dia. x 1" pin 1,000 GCN150, GCN-MEP, TF1100, C3, C4
GDP-125KT .106 dia. x 1¼" pin 1,000 GCN150, GCN-MEP, TF1100, C3, C4
GDP-150KT .106 dia. x 1½" pin 1,000 GCN150, GCN-MEP, TF1100, C3, C4
GDP Collated Step-Shank Pins (GCN-MEP tool requires GCN-MEPMAG)
Model No. Description Qty Pins/ pack +1 Fuel Cell Compatible Gas-Actuated Nailer
GDPS-50 1.09”/1.11" dia. x ½" pin 1,000 GCN150, GCN-MEP, TF1100, C3, C4
GDPS-62 1.09”/1.11" dia. x
5
⁄8" pin 1,000 GCN150, GCN-MEP, TF1100, C3, C4
GDPS-75 1.09”/1.11" dia. x ¾" pin 1,000 GCN150, GCN-MEP, TF1100, C3, C4
GDP Collated Spiral-Knurled Pins (GCN-MEP tool requires GCN-MEPMAG)
Model No. Description Qty Pins/ pack +1 Fuel Cell Compatible Gas-Actuated Nailer
GDPSK-138KT .110 dia. X 1
3
⁄8" spiral knurled pin 1,000 GCN150, GCN-MEP
Mechanical, Electrical and Plumbing Pins
All single-shot pins are .125” diameter and 1” in length unless specied.
Model No. Description Pack Qty. Compatible Gas-Actuated Nailer
GRH25-R100
1
⁄ 4 " Rod Hanger with Pin 100 GCN-MEP, T3
GRH37-R100
3
⁄8" Rod Hanger withPin 100 GCN-MEP, T3
GCC50-R100
1
⁄ 2 " Conduit Clip w/Pin 100 GCN-MEP, T3
GCC75-R100
3
⁄ 4 " Conduit Clip w/Pin 100 GCN-MEP, T3
GCC100-R100 1" Conduit Clip w/Pin 100 GCN-MEP, T3
GCC125-R50
1" Conduit Clip (13 Gauge Steel) w/
.125 Dia. x 1" Length Pin
50 GCN-MEP, T3
GCL50-R50
1
⁄ 2 " Conduit Clamp w/Pin 50 GCN-MEP, T3
GCL75-R25
3
⁄ 4 " Conduit Clamp w/Pin 25 GCN-MEP, T3
GAC-R100 Angle Clip w/Pin 100 GCN-MEP, T3
GCT-R50 Tie Strap Holder w/Pin 50 GCN-MEP, T3
GW50-R200
1
⁄ 2 " Dome Washer with .110”/.128” Dia.
x
1
⁄ 2 " length step-shank pin
200 GCN-MEP, T3
GW75-R200
1
⁄ 2 " Dome Washer w/ .125 Dia. x
3
⁄ 4 "
Length Pin
200 GCN-MEP, T3
GW100-R100
1
⁄ 2 " Dome Washer w/Pin 200 GCN-MEP, T3
GTS4-5075-R200
1
⁄ 4 -20 thread,
1
⁄ 2 " length thread,
3
⁄ 4 "
length shank (.127" dia shank)
200 GCN-MEP, T3
GBR2-R25 2" Dia. Ring, w/Pin 25 GCN-MEP, T3
GTH-R200 Tophat Pin 200 GCN-MEP, T3
Model No. Description Pack Qty. Packs/ Carton Compatible with these Tools
GFC34 34 gram fuel cell 12 —
SimpsonStrong-Tie
®
GCN-MEP and GCN-150 Others:
TF1100, C3, C4
GFC34-RC2 (2) 34 gram fuel cells 2 6
SimpsonStrong-Tie
®
GCN-MEP and GCN-150 Others:
TF1100, C3, C4
Gas Fuel Cells for GCN Tool
