14
16
15
12
19
18
17
20
12. Handle stop pin
13. Choke
14. Fuel valve
15. Starter recoil
16. Support bracket
17. Engine oil drain plug
18. Oil dipstick
19. Battery tray (electric start models only)
20. Control panel
21. Frame ground terminal
22. Spark arrestor (if equipped)
22
21
13
NOTE: Line drawings used in this manual may not represent your specic model.
