SUREFIRE ELECTRONIC IGNITION SYSTEM
S.I.T. PROFLAME 1 TROUBLESHOOTING
SimTech Proflame I
Diagram 19
This example shows the fan set on level 4 and the 110 Volt Auxiliary mode turned on.
Fan Icon
Indicates Fan is active
Auxiliary Accent Light Icon
Icon Shows OFF
Icon Shows ON
